VME/VPX Open Frame Chassis
筐体 / OpenVPX
・Description: Open Frame Chassis for 220mm deep cards. ・Size: 17.24" wide x 21.3" high x 15.37" deep ・Slot Count: 10 Slots Mixed Pitch. 220mm deep cards. ・Supported Bus Structures: VPX (VITA 46/48/65/68) and VME64x ・Cooling: (3) High Performance 130 CFM Fans provide >20 CFM per slot (Adjustable Knob Control on Front Panel). Air cooled chassis and b…
OpenVPX NVIDIA Fermi GPGPU 3U Quick Start Kit
GPGPU / OpenVPX
・VPX3-1257 Intel third generation Core i7 SBC ・2.1 GHz quad-core i7 CPU with AVX ・8 GB DDR3 ・8 GB SSD ・VPX3-491 NVIDIA Fermi GP-GPU board ・240-core Fermi class GPUs ・2 GB of GDDR5 ・6-slot 3U 1” pitch OpenVPX™ Desktop Chassis ・5-slot full mesh ・500 W power supply, 110V/220V input
VPX6-1958 6U VPX Intel Core i7 Haswell SBC
CPUボード / OpenVPX
・6U VPX™ form factor ・Intel® 4th Generation Core™ i7 Quad-Core 22nm processor, Haswell ・2.4 GHz ・Quad-Core CPU ・6 MB L3 cache ・Intel AVX Floating Point ・Up to 32 GB DDR3 SDRAM ・32-64 GB NAND flash drive ・Intel VT-d & TxT support ・Two XMC sites + one PMC site ・Intel Graphics: (2) DVI and (1) VGA ・Additional I/O: ・(4) Gigabit Ethernet (Dual…
3U/6U 8-slot OpenVPX Backplane
筐体 / OpenVPX
・Description: Custom hybrid OpenVPX Backplane ・Slot Count: 2x 3U OpenVPX and 14x 6U OpenVPX ・Supported Bus Structures: OpenVPX (VITA 65/68) ・Size: 6U
CHAMP-FX3 (VPX6-472) 6U OpenVPX Virtex-6
FPGAモジュール / OpenVPX
・6U OpenVPX (VITA 65) ・Dual user-programmable Xilinx Virtex-6 FPGAs (SX475T or LX550T), each with: ・2 GB DDR3 SDRAM in two banks ・Supports migration to 4 GB per FPGA ・72 MB QDRII+ SRAM in four banks ・Freescale Power Architecture MPC8640D processor ・Running at 1 GHz ・1 GB SDRAM in two banks ・Two Mezzanine sites with support for FMC (VITA …
NETernity™ GBX410
スイッチ/ルーター / OpenVPX
・Expands to 24-port non-blocking solution ・Available in air-cooled and conduction-cooled formats ・Unmanaged version available ・Configuration through web interface ・44 Gb/s non-blocking switch fabric with full wire speed performance ・3U VPX form factor ・Layer 2/3 switching with advanced support for VLANs, QoS and IPv6 ・For Ruggedization Levels, plea…
VPX514
FPGAモジュール / OpenVPX
・VPX FPGA carrier for FPGA Mezzanine Card (FMC) per VITA-57 ・VPX514 only takes power from the VPX chassis (there are no other interfaces going to the back plane) ・Dual 10GbE via SFP+ interfaces ・Xilinx Virtex-6 FPGA in FF1759 package ・On board PLL for buffering/multiplying and jitter cleaner ・Option for up to 4GB of DDR-III memory ・On board Freesca…
RME 8U-13U Air-cooled Enclosures
筐体 / OpenVPX
・Description: RME Enclosure Solutions ・Cooling: Air cooled chassis and boards ・Size: 19" Rackmount Enclosures ranging from 8U, 9U, 10U and 13U ・Slot Count: varies. ・Supported Bus Structures: VPX, OpenVPX, VPX-REDI (VITA 46/48/65/68), VME, VME64x, VXS (VITA 41) and CompactPCI (cPCI)
VPX6-185 Dual Freescale 8640 SBC
CPUボード / OpenVPX
・Powerful general-purpose single board computer with Freescale 8640 PowerPC processor ・Single or dual processor e600 cores at up to 1.33GHz ・Up to 2 GB DDR2 SDRAM controlled by dual 64-bit controllers ・Full complement of I/O capability (Ethernet, SCSI, serial, USB 2.0, 1553, Serial ATA, TTL and differential discretes) ・Two 64-bit PMCs on independen…
6U 5-slot MPMC-9650
筐体 / OpenVPX
・Processing ・Intel Core Duo or Freescale Power Architecture™ MPC7448 ・Optional Interfaces ・MIL-STD-1553 - Up to two dual redundant channels ・ARINC 429 - Up to 32 channels ・Individually selectable as Rx or Tx ・Video up to four outputs ・DVI, LVDS or VGA ・Optional PowerPC video processor ・Video input, up to six channels ・(NTSC, P…
