ICS-1640
その他 / PCI Express
・16-channel, 2.5 MHz Sigma-Delta 24-bit ADC ・Short form factor ・Fully differential inputs ・Better than 100 dB dynamic range ・PCIe x4 interface ・Internal/external clock ・Internal clock programmable with resolution of 1 Hz ・10 MHz onboard TCXO reference ・16 MB onboard storage ・Windows and Linux Software Development Kits ・ICS-1640 Press Release ・Senso…
ICS-8551
その他 / PMC/XMC
・4 AC-coupled Analog Inputs ・Fs ≤ 1.5 GHz 4-channel, or 3 GHz 2-channel (software selectable), 8-bit ・Xilinx Virtex-4 User Programmable FPGA FX60 ・TCXO @ 10 MHz ・8-plug Samtec GRF1-J connector (Ruggedization Levels 1, 2 and 3) ・8 individual MMCX Coaxial Connectors (Ruggedization Levels 4 and 5) ・PCI 2.2 64-bit, 66 MHz Master/Target Burst Mode DMA c…
CPCI-5579
通信I/O / CompactPCI
・Any node on the network can generate an interrupt in any other node on the network or in all network nodes with a single command ・Data transferred at 6.7 Mbyte/s with redundant transfer ・Data transferred at 13.4 Mbyte/s without redundant transfer ・Up to 1,000 m between nodes and up to 256 nodes ・Data written to memory in one node is also written t…
G2 Graphics PMC Module
グラフィック / PMC/XMC
・Supports a full range of monitor types and resolutions ・Three levels of ruggedness - commerical, extended and conduction cooled ・Powerful graphics processing from ATI Radeon® 9000 ・Graphics PMC for video capture, processing and display ・Single display, dual display and video capture configurations
PMC695TX
通信I/O / PMC/XMC
・IBM 440GP processor ・eTCP embedded TCP/IP firmware ・One 10/100BaseTX Ethernet port ・One RS232 port ・1000BaseT Ethernet port ・Capable of handling full wire speed traffic ・High performance PPC at 466MHz on board ・PCI 64-bit / 66MHz ・Universal 3.3V and 5V signaling ・Not recommended for new designs
NETernity™ RM920
スイッチ/ルーター / VMEbus
・Motorola XPC8240 management processor ・Managed solution ・Full wire speed ・Combination of copper / fiber ports ・20 front panel ports; 4 ports routed to rear I/O ・24 Port Gigabit Switch (dual slot) ・Layer 2/3/4 Switching ・6U VME form factor ・Industrial temperature version available ・12-port single slot version available
NETernity™ CP3-GESW8
スイッチ/ルーター /
・One front panel port ・IEEE 802.3 compliant ・8-port 10/100/1000BaseT Ethernet line speed switching ・Standalone board, no host CPU intervention required ・Easy setup and operation ・Seven rear access ports ・Not recommended for new designs
GS12
スイッチ/ルーター /
・Fully, rugged standalone Gigabit Ethernet Switch ・12-port fully managed 10/100/1000BaseT (Gigabit) Ethernet Switch ・1 x 10/100BaseT management port ・Layer 2/3 switching with advanced support fo VLANS, QoS and IPv6 ・24 Gbits/sec non-blocking switch fabric with full wirespeed performance ・Configuration through Web interface ・Unmanaged version also a…
Power7E
CPUボード / VMEbus
・Two RS-232 serial ports ・PowerPC 750 up to 500 MHz; 83 MHz system bus ・64 MB to 1 GB SDRAM with ECC at 83 MHZ ・10BaseT/100BaseTX Ethernet with RJ-45 connector
VME-7700RC
CPUボード / VMEbus
・2x Front Panel USB ・650 MHz Ultra Low Voltage Pentium Celeron Processor ・Up to 1 GB of bootable Flash on secondary IDE (optional) ・PMC expansion site
