3U/6U 9-slot OpenVPX Backplane
筐体 / OpenVPX
・Description: Custom hybrid OpenVPX Backplane ・Slot Count: 2x 3U OpenVPX and 7x 6U OpenVPX ・Supported Bus Structures: OpenVPX (VITA 65/68) ・Size: 6U
CHAMP-AV8 6U OpenVPX
CPUボード / OpenVPX
・Two Intel Core i7-3612QE quad-core processors at up to 2.1GHz ・4 Gbytes DDR3 SDRAM with ECC per processor ・8GB NAND flash per processor ・256 Kbytes NVRAM ・Gen2 Serial RapidIO Data Plane interface, 8GB/s bi-directional bandwidth ・Gen2 PCI Express Expansion Plane interface on P2, up to 8GB/s bidirectional bandwidth ・Two 1000BASE-T, two 1000BASE-BX E…
FMC-516 Quad 250MSPS 16b ADC FMC
アナログI/O / FMC
・Analog Input: ・Number of Channels: 4, single-ended ・Sampling Frequency: Up to 250MSPS ・Full Scale Input Voltage: 18.8 dBm ・Device: 4x Intersil ISLA216P25 ・Input Bandwidth (3dB): up to 500 MHz ・SFDR (at 105 MHz): 84 dBFS (typ) ・SNR (at 105 MHz): 70 dBFS (typ) ・ENOB (at 105 MHz): 11.3 bits (typ) ・Input Impedance: 50 Ohm, AC coupled…
11U Shipborne RF Chassis
筐体 / その他の規格
・Description: Shipboard RF Solution. Shipborne chassis with RF blind mate through backplane. IEEE 1101.10 mechanical packaging with 6U x 220MM card cage. RF coax contacts feed through the backplane. Integrated with RF semi-flex coax cables. ・Size: 19" Rackmount x 11U high x 24" deep ・Slot Count: 20 Slots 0.8" Pitch ・Cooling: Air cooled chassis and …
SWI-22-10 PCI104 Gigabit Ethernet Switch
その他 / PC104
High Port Density • Up to 20 Ports of Gigabit Ethernet Switch Ports in Single-Slot PCI/104-Express Form Factor (3.6”x3.8”) Card; Eight (8) Port Option Roadmapped Rugged Design • -40/+85C Extended Temp, Vibration Tolerant Connectors for Cableless/Cabled Network Connections, Staked & Underfilled Components Carrier Grade • Carrier Ethernet (CE) Swi…
VME, VPX, VXS Recorders
グラフィック / OpenVPX
・Web-based Graphical User Interface (GUI) or Application Programming Interface (API) ・Seismic data acquisition and physics research ・Ready-to-run or customer programmable features ・Scalable utilizing Fibre Channel Storage Area Network (SAN) technology ・Compact using our VXS SATA disk carrier utilizing HDD or SSD ・Commercial or rugged versions
CHAMP-AV8 6U OpenVPX
CPUボード / OpenVPX
・Two Intel Core i7-3612QE quad-core processors at up to 2.1GHz ・4 Gbytes DDR3 SDRAM with ECC per processor ・8GB NAND flash per processor ・256 Kbytes NVRAM ・Gen2 Serial RapidIO Data Plane interface, 8GB/s bi-directional bandwidth ・Gen2 PCI Express Expansion Plane interface on P2, up to 8GB/s bidirectional bandwidth ・Two 1000BASE-T, two 1000BASE-BX E…
1 ATR Short Air Conduction Enclosure
筐体 / VMEbus
・Description: 1 ATR Air / Conduction Cooled Enclosure with Air Cooled Card Cage, side walls and integral fans ・Size: 1 ATR Short ・Cooling: Conduction Cooled Boards and Chassis ・Slot Count: 8 slot ・Chassis Type: ATR ・Power Supply: MIL-STD-704 Power Supply ・Supported Bus Structures: VPX, OpenVPX, VPX-REDI (VITA 46/48/65/68), VME64x, VXS (VITA 41) and…
Front Panels/Faceplates
筐体 /
・Elastomeric EMI gaskets eliminate problems found in competitive metal gaskets (no sharp edges, no snags) ・Offered in various widths and heights ・1” VITA 48.1 REDI compliant versions also available ・An assortment of handles is available
6U 5-slot MPMC-9H5x
筐体 / OpenVPX
・Form factor: 1/2 ATR with hybrid backplane (1x VME, 2x 6U VPX, and 2x 3U VPX) ・Mechanical ・Natural convection cooling ・Volume optimized size: 14.2" x 9.0" x 9.1" ・Freescale Power Architecture MPMC8610 processor ・28V DC MIL-STD-704 compliant power supply
