ATC807
通信I/O / AdvancedTCA
・AdvancedTCA open standard form factor ・PICMG 3.1 compliant ・Managed Layer two 10GbE and 1GbE switch ・10GbE to the Fabric channel for 15 Node slots (option 9 or 1 selectable per port basis) ・GbE to Base Interface for 15 Node slots plus two Shelf ・Eight SFP+ cages for 10GbE ports (each port can run as GbE or 10GbE) ・Eight front panel 10/100/1000 Mbi…
AMC215
通信I/O / AdvancedMC
・AMC.2 compliant (XAUI based) ・10GbE via SFP+ ・XFI-to-XAUI operation ・Integrated Loopback and Line Timing Functionality ・Fully Adaptive Electronic Dispersion Compensation (EDC) ・Integrated BER Tester, and PRBS, Packet, and programmable Pattern Generation and checking. ・Compliant to applicable IEEE and INCITS specs
PEAZ-5565
通信I/O / その他の規格
・Local or remote monitoring options ・Flexible triggers ・Large trace buffer ・Complex trigers ・Local or remote Analyzer package installation ・Support for capturing and inspecting bad packets
PMC615RC
通信I/O / PMC/XMC
・Full duplex operation in both 10/100 modes ・PCI 66MHz capable ・Includes PIM ・J4 connectors ・Rear access I/O ・Four 10/100BaseTX Ethernet interface ・Pericom PIC8150 PCI bridge ・RoHS compliant
PMC676RCSC
通信I/O / PMC/XMC
・Jumbo Frames capable ・Full 1000Mbit point-to-point performance ・Dual or single 1000Mbit fiber Ethernet ・DMA engine ・Connector options SC ・Options: 1000BaseLX, single port, LC connectors, Solaris OBP boot option, PXE boot option, acrylic or polyurethane conformal coating ・PCI-X, PCI 64-bit/66MHz ・RoHS compliant
RXMC2-1553
通信I/O / PMC/XMC
・XMC.3 (1x PCIe) host interface ・Simultaneous Bus Controller, up to 31 Remote Terminals and Bus Monitor ・High-level API for Windows 7 (32 and 64 bit), Vista, XP, VxWorks, Linux, and Solaris included. Contact your local sales representative for additional operating system support. ・12 Bi-directional Avionics level discretes individually configurable…
AMC721
通信I/O / AdvancedMC
・Single-width, mid-height (option for full-height) per AMC.0 ・Processor AMC with Intel Next Generation Core i (Gladden) with Cave Creek PCH ・Serial over LAN ・IPMI 2.0 compliant ・RoHS compliant ・Dual 10GbE XAUI on ports 4-7 and 8-11 (AMC.2) ・GbE to port 0 and 1 (AMC.2) ・SATA to port 2 and 3 (AMC.3) ・Dual GbE to the front panel ・Up to 16GB of DDR-III…
AMC205
通信I/O / AdvancedMC
・AMC.1 ・SMid-height and full-height options ・PCIe x8 lanes ・Optional Fiber or Copper Front Panel Interface ・IPMI 2.0 Compliant ・RoHS Compliant ・Support for: Linux, Windows, Solaris and VxWorks ・Four Gigabit Ethernet SFP Ports ・Copper (RJ-45) ・Fiber SX (850 nm) ・Fiber LX (1310 nm)
PMC-5565
通信I/O / PMC/XMC
・Error detection ・Redundant transfer mode for extra error suppression ・Any node on the network can generate an interrupt in any other node on the network or in all network nodes with a single command ・Two independent DMA channels ・64 Mbyte or 128 Mbyte SDRAM Reflective Memory ・Transfer rate 43 Mbyte/s (4 byte packets) to 174 Mbyte/s (64 byte packet…
PMC696LC
通信I/O / PMC/XMC
・Trunking capabilities ・Fail-over firmware ・64MB of DDR SDRAM onboard (optional 128MB) ・Options: 1000BaseLX ・PCI 64-bit / 66MHz ・LC connectors ・High performance RISC processor on board ・Dual 1000BaseSX Ethernet ports ・Not recommended for new designs
